a.Detailed Product Description |
1)AWWA:C219 |
BS 34:1990 |
BS 772:1998 |
SA S 1802-2:1998(SABS 1802-2:1998) |
2)DN40mm-600mm |
3)PN10/16/25 |
4) suit for steel PVC .ductile iron, asbestos cement, GRP . cast iron and concrete pipes |
5)use:for air, water ,sewer and gas pipelines |
b.Material and coating |
1)End rings-ductile iron to BS2789 grade 420/12, 500/7 |
2)Sleeves-ductile iron to BS2789 grade 420/12,500/7 or steel to SABS 1431 grade 300WA |
3)Coating –fusion Bonded epoxy to SABS1217, minimum thickness 250 microns, colors in RAL5005, RAL5015, RAL3009, RAL9005, RAL9011 or others |
4)Bolts-steel to BS970 grade 070M20.Grade 4.8, carbon steel Grade 8.8, SS304 or SS316 Bolts available upon requests. |
5)Bolt coating-dacromet, or galvanized |
c. Gasket: |
Rubber seal-E.P.D.M Grade E to BS2494 1990 Type W&D |
